Description
Incorporating key Cinema EOS video tools in a mirrorless- style body, the Canon EOS C70 Cinema Camera features a Super35 DGO (Dual Gain Output) sensor for capturing nuanced images with up to 16+ stops of high dynamic range. The innovative DGO system combines two separate gain readings for each photodiode on the sensor, emphasizing saturation in bright areas of your image and lowering noise in darker areas.
Pro video functions include unlimited video recording, a motorized ND filter wheel tucked into the shallower RF-mount flange depth, a BNC timecode input/output connector, and built-in dual mini-XLR audio inputs. The EOS C70 is also the first Cinema EOS camera with an RF mount that enables you to use Canon's line of fast, reliable RF lenses with advanced coatings and image stabilization.
Further pro video features include Dual Pixel CMOS AF autofocus control and up to 4K 120p or Super 16 2K crop 180 fps capture. This lightweight cine camera also incorporates a 3.5" Direct Touch Control LCD panel for quick, easy setting changes, and both auto-ISO and auto-gain functions for on-the-go adjustments to changing light levels.
The EOS C70 Cinema Camera fits into your C300 Mk III workflow as a B camera, as an upgrade for C200 or C100 users, or as an alternative for EOS R owners who are shooting an increasing amount of video. Its touchscreen LCD panel speeds your workflow by enabling you to turn functions on and off directly from the touchscreen; no need to spend time going into multiple menus via a combination of control buttons and jog wheels. Power the EOS C70 using a BPA-60 or BPA-30 battery or the included AC power adapter.
To provide greater flexibility in lens choices, the EOS C70 camera is also compatible with the separately available EF-EOS R 0.71X EF to RF lens mount adapter. This adapter converts your full-frame lenses to Super35 format while also providing a handy aperture speed boost of around one stop. The EF adapter passes all the EF lens data through the RF mount, providing full Dual-Pixel Auto Focus and metadata information for select lenses. The EOS C70 is also the first Canon EOS cinema camera to feature the EOS iTR AF X autofocus function, which uses a head-tracking algorithm developed with deep-learning technology for improved distance measuring and tracking reliability.
This digital cine camera records up to DCI 4K resolution video to dual slots using widely available and more affordable SD cards. High frame rates can be recorded in 4K up to 120 fps and up to 180 fps in a 2K cropped Super16 mode. Codec options include Canon's XF-AVC, XF-AVC Intra, and XF-AVC Long GOP, providing up to 10-bit, 4:2:2 DCI 4K images with reduced storage requirements. To boost your post-production workflow, the flexible EOS C70 supports both proxy recording rates and simultaneous recording in different formats, including 4K/HD and XF-AVC/MP4 options. The EOS C70 can also capture still images to SD cart slot B when in standby in select video modes.
For greater flexibility during post-production, this camera also offers Canon's Log 2 and Log 3 gamma modes, both of which provide an expanded dynamic range with excellent tonal reproduction for highlights and in low-light areas of your images. The EOS C70 also supports .cube 3D LUTs so you can get the most accurate color reproduction on both the LCD and your external viewing monitors.
This cinema camera features one HDMI Type-A output, a BNC timecode input/output, and a USB Type-C port for control or linking to an external Wi-Fi adapter for streaming. It supports up to 4-channel audio using dual mini-XLR ports, an internal stereo mic, and a 3.5mm mic input. The EOS C70 body comes with a detachable handle unit, a mic holder, a shoulder strap, one BPA-30 battery, a battery charger, an AC adapter with power cord, and a port cap.
Specification
Image Sensor Size | 26.2 x 13.8 mm (Super35) |
Sensor Type | CMOS |
Sensor Resolution | Actual: 4206 x 2280 (9.6 MP) Effective: 4096 x 2160 (8.85 MP) |
Sensor Windowing | 2048 x 1080 in 16:9 When Recording in Super 16 |
Pixel Pitch | 6.4 µm |
Color Filter | Bayer |
Shutter Type | Rolling Shutter |
ISO | 100 to 102,400 |
Gain | -6 to 54 dB (Native) -2 to 54 dB (Expanded) |
Advertised Dynamic Range | 16 Stops |
Lens Mount | Canon RF |
Lens Communication | Yes |
Shutter Speed | 1/12 to 1/2000 sec (In 60p Mode) 1/15 to 1/2000 sec (In 50p Mode) |
Shutter Angle | 11 to 360° |
Built-In ND Filter | Mechanical Filter Wheel with Clear, 2 Stop (1/4), 4 Stop (1/16), 6 Stop (1/64), 8 Stop (1/256), 10 Stop (1/1024) ND Filters |
Built-In Microphone Type | Stereo Mono |
Recording Media | 2 x SDXC/SDHC Card Slots |
Variable Frame Rates | DCI 4K: 12 Up to 120 fps DCI 2K (Windowed): 12 Up to 180 fps |
Recording Modes | H.264/H.265/MP4/XF-AVC/XF-AVC Proxy 4:2:2 10-Bit: 4096 x 2160p up to 23.98/24/25/29.97/50/60 fps (160 to 260 Mb/s) 3840 x 2160p up to 23.98/24/25/29.97/50/60 fps (160 to 260 Mb/s) 2048 x 1080p up to 23.98/24/25/29.97/50/60 fps (50 Mb/s) 1920 x 1080p up to 23.98/24/25/29.97/50/60 fps (50 Mb/s) H.264/H.265/MP4/XF-AVC/XF-AVC Proxy 4:2:2 10-Bit: 4096 x 2160p up to 119.88/120 fps 3840 x 2160p up to 119.88/120 fps H.264/H.265/MP4/XF-AVC/XF-AVC Proxy 4:2:2 8-Bit: 2048 x 1080p up to 179.82/180 fps 1920 x 1080p up to 179.82/180 fps H.264/H.265/MP4/XF-AVC/XF-AVC Proxy 4:2:0 8-Bit: 2048 x 1080p up to 23.98/24/25/29.97/50/59.94 fps (24 to 35 Mb/s) 1920 x 1080p up to 23.98/24/25/29.97/50/59.94 fps (24 to 35 Mb/s) H.264/H.265/MP4/XF-AVC/XF-AVC Proxy 4:2:2 10-Bit: 4096 x 2160p up to 23.98/24/25/29.97/50/59.94 fps (135 to 225 Mb/s) 3840 x 2160p up to 50/59.94 fps (135 to 225 Mb/s) 2840 x 1080p up to 23.98/24/25/29.97/50/59.94 fps (50 Mb/s) 1920 x 1080p up to 23.98/24/25/29.97/50/59.94 fps (50 Mb/s) 1280 x 720p up to 50/59.94 fps (12 Mb/s) H.264/H.265/MP4/XF-AVC/XF-AVC Proxy 4:2:0 10-Bit: 4096 x 2160p up to 23.98/24/25/29.97/50/59.94 fps (100 to 170 Mb/s) 3840 x 2160p up to 23.98/24/25/29.97/50/59.94 fps (100 to 170 Mb/s) 2048 x 1080p up to 23.98/24/25/29.97/50/59.94 fps (35 Mb/s) 1920 x 1080p up to 23.98/24/25/29.97/50/59.94 fps (35 Mb/s) 1280 x 720p up to 50/59.94 fps (9 Mb/s) H.264/H.265/MP4/XF-AVC/XF-AVC Proxy 4:2:2 10-Bit: 4096 x 2160p up to 119.88/120 fps 3840 x 2160p up to 119.88/120 fps 2048 x 1080p up to 179.82/180 fps 1920 x 1080p up to 179.82/180 fps H.264/H.265/MP4/XF-AVC/XF-AVC Proxy 4:2:0 8-Bit: 4096 x 2160p up to 23.98/24/25/29.97/50/59.94 fps (150 Mb/s) 3840 x 2160p up to 23.98/24/25/29.97/50/59.94 fps (150 Mb/s) 2048 x 1080p up to 23.98/24/25/29.97/50/59.94 fps (35 Mb/s) 1920 x 1080p up to 23.98/24/25/29.97/50/59.94 fps (35 Mb/s) 1280 x 720p up to 50/59.94 fps (8 Mb/s) H.264/H.265/MP4/XF-AVC/XF-AVC Proxy 4:2:2 8-Bit: 4096 x 2160p up to 119.88/120 fps 3840 x 2160p up to 119.88/120 fps 2048 x 1080p up to 179.82/180 fps 1920 x 1080p up to 179.82/180 fps |
Gamma Curve | Canon Log 2, Canon Log 3, HDR-HLG, HDR-PQ, Wide DR |
Audio Recording | 4-Channel 24-Bit 48 kHz LPCM Audio |
Still Image Support | JPEG |
Video Output | 4:2:2 10-Bit via HDMI: 4096 x 2160p at 23.98/24/25/29.97/50/59.94 fps 3840 x 2160p at 23.98/24/25/29.97/50/59.94 fps 1920 x 1080p at 23.98/24/25/29.97/50/59.94 fps 2048 x 1080p at 23.98/24/25/29.97/50/59.94 fps 1280 x 720p at 23.98/24/25/29.97/50/59.94 fps |
Video Connectors | 1 x HDMI Output |
Audio Connectors | 2 x Mini XLR Mic/Line Level (+48 V Phantom Power) Input 1 x 1/8" / 3.5 mm Stereo Input 1 x 1/8" / 3.5 mm Stereo Headphone Output |
Other I/O | 1 x USB Type-C Control, Video Input/Output 1 x BNC Timecode Input/Output 1 x 2.5 mm LANC Control |
Display Type | Articulating Touchscreen LCD |
Size | 3.5" |
Resolution | 2,760,000 Dot |
EVF | Optional, Not Included |
Battery Type | Canon BP-A Series |
Power Connectors | 1 x Barrel (11.5 to 20 VDC) Input |
Operating Temperature | 32 to 104°F / 0 to 40°C (Recommended) |
Operating Humidity | 85% (Recommended) |
Tripod Mounting Thread | 1/4"-20 Female (Bottom) 1/4"-20 Female (Side) |
Dimensions | 6.3 x 5.1 x 4.6" / 160 x 130 x 116 mm |
Weight | 2.58 lb / 1.17 kg |
Product Includes
